Product Details:
|
| Relative Density: | 0.99 | Viscosity: | 500-3000 |
|---|
PROFILE
G-206-4 is a alicyclic amine modified epoxy curing agent presented as a yellow viscous liquid with low viscosity, excellent powder-loading capacity, high cured-block hardness, and superior water resistance. It can incorporate powder fillers up to six times its own weight, and maintains a hardness of 80 Shore D after immersion in water for one month.
ADVANTAGES
Powder can be added, and the bonding strength is high.
High cost performance.
Good water resistance.
APPLICATIONS
Dry hanging glue.
Floor mid-coat.
Bonding and other fields.
STORAGE
It should be sealed in its original packaging and stored in a dry place at a temperature range of 0-40°C (the temperature must not fall below 0°C). It should not be placed in direct sunlight.
INDEX
|
Appearance |
Yellow liquid |
| Viscosity (25℃) |
500-3000 |
| Relative density (g/ml/25℃) |
0.99 |
| Active Hydrogen Equivalent Weight (AHEW) |
156 |
|
Grams of epoxy curing agent required for 100 grams of E-51 epoxy resin |
80 |
|
Amine value (hydrochloric acid method) |
265±30 |
BASIC FEATURES
| Pot life (25°C, 100g): | 30-50 min |
| Film Drying Time (3mm, 25°C) |
1.5-4h |
| Shore D Hardness 48h |
＞80 |
|
Steel-to-steel shear① |
≥15MPa |
|
Bending elasticity |
＞4000 |
Note: ① Above experimental data: YD-128 resin/G-206-4 hardener = 100/80, add two times the mass of powder. Curing conditions: 25℃×24h, 80℃×1h
Basic data is based on the E-51 epoxy resin (E-51 is bisphenol A type, with an epoxy equivalent of 180-190).
