Product Details:
|
The high elasticity of polyaspartic comes from its unique molecular structure and dynamic cross-linked network, enabling it to stretch under stress and rapidly return to its original shape.
Segment Design of Molecular Chains
1.Soft Segments (Flexible Chains)
Polyether/Polyester segments: Typically, polyaspartic incorporates flexible segments like polytetramethylene glycol (PTMG) or polycaprolactone (PCL), which impart chain mobility.
Function: These flexible segments stretch and coil under external forces, providing high elongation rates (generally >300%).
2.Hard Segments (Rigid Chains)
Carbamate bonds (-NH-CO-O-): Formed by reactions between isocyanates and aspartic esters, creating rigid cross-linking points to limit excessive molecular chain sliding.
Function: Hard segments form physical cross-links via hydrogen bonds and Van der Waals forces, enhancing tensile strength (>20 MPa).
3.Microphase Separation Structure
Soft and hard segments spontaneously form microphase separation due to thermodynamic incompatibility:
Dynamic Characteristics of Cross-linked Networks
1.Three-dimensional Cross-link Density
Polyaspartic forms a moderate cross-link density via chemical cross-linking between isocyanates and aspartic esters:
2.Reversible Hydrogen Bonding
Dynamic hydrogen bonds form between the N-H and O=C in carbamate groups:
Experimental Data on Elastic Properties
1.Tensile Properties (ASTM D412)
Elongation at break: 300%-500% (traditional epoxy resin: 3%-5%, polyurethane: ~200%).
Elastic modulus: 100-500 MPa (moderate rigidity, balancing flexibility and support).
2.Dynamic Mechanical Analysis (DMA)
Glass transition temperature (Tg): Typically between -50°C to 0°C, maintaining elasticity at low temperatures (typical rubber: Tg ~-60°C; epoxy resins: Tg >50°C).
Tan δ peak value: Low (around 0.1-0.3), indicating low energy loss and high resilience.
3.Cyclic Compression Test
Polyaspartic exhibits <5% permanent deformation after 1000 cycles at 50% compression strain (silicone rubber: ~10%, polyurethane: ~15%).
Practical Applications of Elastic Advantages
1.Industrial Flooring
Impact resistance: Elastic coating absorbs energy from forklifts and falling objects, protecting concrete substrates from cracking.
Case: Automotive factory flooring coated with polyaspartic reduced equipment maintenance by 60%.
2.Sports Surfaces
Energy return: Elastic coatings on tracks and courts reduce joint impact (rebound rate >35%), enhancing safety.
3.Bridge Expansion Joints
Deformation adaptability: Coatings elastically deform with bridge movements within -30°C to 70°C, preventing cracks and water ingress.
4.Protective Coatings
Blast resistance: Coatings in military and chemical plants dissipate shockwave energy through elasticity.
Comparison with Traditional Elastic Materials
Adjustments of Elastic Performance
1.Segment Proportion Adjustments
Increasing soft segments: Boosts elongation (e.g., PTMG content from 30% to 50% increases elongation from 300% to 450%).
Increasing hard segments: Raises modulus (e.g., excess isocyanates increase modulus from 100 MPa to 300 MPa).
2.Functional Modifications
Nanoreinforcement: Adding carbon nanotubes (CNT) or graphene enhances elastic modulus (+20%) while maintaining high elongation.
Toughening agents: Introducing core-shell particles (e.g., acrylates) improves tear resistance.
3.Dynamic Cross-linking Techniques
Reversible covalent bonds: Incorporating Diels-Alder bonds achieves self-healing elasticity (currently at laboratory stage).
The elasticity of polyaspartic results from the cooperative effect of microphase separation between soft and hard segments and the dynamic cross-linked network. Through flexible molecular chain design, reversible hydrogen bonding, and appropriate cross-link density, polyaspartic achieves high elongation, rapid rebound, and durability. This balance between rigidity and flexibility makes polyaspartic an indispensable high-performance elastic material in industries such as manufacturing, construction, and transportation. Future developments in smart dynamic bonding will further enhance its elasticity control and self-healing properties, expanding applications in flexible electronics and intelligent coatings.
Feiyang has been specializing in the production of raw materials for polyaspartic coatings for 30 years and can provide polyaspartic resins, hardeners and coating formulations.
